1" x 4cf Water Softener

Craft Brew Water



Automatic 4 cubic foot Water Softener. Comes complete with brine tank and metered valve with 1" Porting through out. 120,000 grain capacity (10 grain hard water system will soften 12,000 gallons. Excellent system for Pre-Treatment for Reverse Osmosis

Includes 2 1" x 24" Stainless Steel Flex Connectors to your order to make installation a snap.

Inlet/Outlet Fittings.................................................................................... 1" NPS
Cycles ....................................................................................................... up to 6
Valve Material............................................................................................ Noryl (1) or equivalent
Regeneration............................................................................................. downflow/upflow
Flow RateS
Service @15 psi drop (includes bypass and meter).................... 27 gpm
Backwash @ 25 psi drop (includes bypass)................................ 27 gpm
Cv Service..................................................................................... 7.0
Cv Backwash................................................................................ 5.4
Operating Pressures
Minimum/Maximum...................................................................... 20 psi – 125 psi
Operating Temperatures
Minimum/Maximum...................................................................... 40º – 110º F
Meter
Accuracy....................................................................................... ± 5%
Flow Rate Range........................................................................... 0.25 – 27 gpm
Gallon Range................................................................................. 20 – 50,000 gallons
Totalizer......................................................................................... 1000 - 9,999,000 gallons
Dimensions & Weight
Distributor Pilot............................................................................. 1.050" OD Pipe (¾" NPS)
Drain Line...................................................................................... ¾” or 1” NPT
Brine Line...................................................................................... 3/8” or ½” OD Poly Tube
Mounting Base.............................................................................. 2 ½” - 8 NPSM
Height From Top Of Tank.............................................................. 7 3/8”
Weight........................................................................................... 4.5 lbs.
Electrical Specifications    AC Adapter
U.S. International
Supply Voltage..............................................................................120V AC.............. 230V AC
Supply Frequency.........................................................................60 Hz................... 50 Hz
Output Voltage..............................................................................12V AC................ 12V AC
Output Current.............................................................................. 500 mA............... 500 mA
Tank Applications
Water Softener.............................................................................. 6” – 21” diameter
Water Filter (2)............................................................................... 6” – 21” diameter
Cycles of Operation (Softener downflow)
Cycle Range of times minutes
1. Backwash 1st (upflow)............................................................... 6 - 12
2. Regenerate Draw/Slow Rinse (downflow)............................... 45 - 75
3. Backwash 2nd (upflow).............................................................. 3 - 12
4. Fast Rinse (downflow).............................................................. 3 - 8
5. Regenerant Refill (in service with treated water)..................... As Programmed
6. Service (downflow)
