2" x 6cf Water Softener

Craft Brew Water



Automatic 6 cubic foot Water Softener. Comes complete with brine tank and metered valve with 2" Porting through out. 180,000 grain capacity (10 grain hard water system will soften 18,000 gallons. Excellent system for Pre-Treatment for Reverse Osmosis or Boiler system.

Includes 2- 2" x 24" Stainless Steel Flex Connectors to your order to make installation a snap.

Inlet/Outlet (1)............................................................................................ 2” Female NPT
Cycles ....................................................................................................... up to 6
Valve Material............................................................................................ Lead free brass
Regeneration............................................................................................. Downflow
COntrol valve Flow RateS
Service @15 psi drop (includes meter)......................................... 115 gpm
Backwash @ 25 psi drop.............................................................. 80 gpm
Cv Service..................................................................................... 29.7
Cv Backwash................................................................................ 16.0
Operating Pressures
Minimum/Maximum...................................................................... 20 psi – 125 psi
Operating Temperatures
Minimum/Maximum...................................................................... 40º – 110º F
Meter specifications
Accuracy....................................................................................... ± 5%
Flow Rate Range........................................................................... 1.5 – 150 gpm
Gallon Range................................................................................. 20 – 1,500,000 gallons
Totalizer......................................................................................... 1 – 9,999,000 gallons
Dimensions & Weight
Distributor Pilot
Valve bodies with 2" Female NPT Inlet & Outlet.................. 1.90” OD (1.5" NPS)
Drain Line Connection.................................................................. 1.5” Female NPT
Brine Line Adapters Included....................................................... 1” Male NPT elbow,
¾” x 1” solvent weld elbow and
1⁄2" OD Poly Tube Compression
Mounting Base.............................................................................. 4” - 8 UN
Height From Top Of Tank.............................................................. 8.5”
Shipping Weight With Meter........................................................ 29 lbs.
Electrical Specifications AC Adapter
Supply Voltage..............................................................................120V AC
Supply Frequency.........................................................................60 Hz
Output Voltage..............................................................................12V AC
Output Current..............................................................................500 mA
Tank Applications
Water Softener.............................................................................. 12” – 48” diameter
Water Filter (2)............................................................................... 12” – 36” diameter
Cycles of Operation
Cycle Range of times minutes
1. Backwash 1st (upflow)............................................................... 1 - 20 or off
2. Regenerate Draw/Slow Rinse (downflow)............................... 1 - 99 or off
3. Backwash 2nd (upflow).............................................................. 1 - 20 or off
4. Fast Rinse (downflow).............................................................. 1 - 20 or off
5. Regenerant Refill (in service with treated water)..................... 0.1 - 99.0 or off
6. Service (downflow)
