1 1/4" x 3cf Water Softener

Craft Brew Water



Automatic 3 cubic foot Water Softener. Comes complete with brine tank and metered valve with 1 1/4" Porting through out. 90,000 grain capacity (10 grain hard water system will soften 9,000 gallons. Excellent system for Pre-Treatment for Reverse Osmosis or Boiler system.

Includes 2- 1 1/4" x 24" Stainless Steel Flex Connectors to your order to make installation a snap.

Inlet/Outlet Fittings.................................................................................... 1 1/4" NPS
Cycles ....................................................................................................... up to 6
Valve Material............................................................................................ Noryl (1) or equivalent
Regeneration............................................................................................. downflow
Flow RateS
Service @15 psi drop (includes meter)......................................... 34 gpm
Backwash @ 25 psi drop.............................................................. 32 gpm (2)
Cv Service..................................................................................... 8.8
Cv Backwash................................................................................ 6.4
Operating Pressures
Minimum/Maximum...................................................................... 20 psi – 125 psi
Operating Temperatures
Minimum/Maximum...................................................................... 40º – 110º F
Meter
Accuracy....................................................................................... ± 5%
Flow Rate Range........................................................................... 0.25 – 34 gpm
Gallon Range................................................................................. 20 – 50,000 gallons
Totalizer......................................................................................... 1000 - 9,999,000 gallons
Dimensions & Weight
Distributor Pilot............................................................................. 1.32" OD Pipe (1" NPS) or 32mm OD
Drain Line...................................................................................... ¾” or 1” NPT
Brine Line...................................................................................... 3/8” or ½” OD Poly Tube
Mounting Base.............................................................................. 2 ½” - 8 NPSM
Height From Top Of Tank.............................................................. 7 3/8”
Weight........................................................................................... 4.5 lbs.
Electrical Specifications    AC Adapter
U.S. International
Supply Voltage..............................................................................120V AC.............. 230V AC
Supply Frequency.........................................................................60 Hz................... 50 Hz
Output Voltage..............................................................................12V AC................ 12V AC
Output Current..............................................................................500 mA................ 500 mA
Tank Applications
Water Softener.............................................................................. 6” – 21” diameter
Water Filter (3)............................................................................... 6” – 24” diameter
Cycles of Operation
Cycle Range of times minutes
1. Backwash 1st (upflow)............................................................... 6 - 12
2. Regenerate Draw/Slow Rinse (downflow)............................... 45 - 75
3. Backwash 2nd (upflow).............................................................. 3 - 12
4. Fast Rinse (downflow).............................................................. 3 - 8
5. Regenerant Refill (in service with treated water)..................... As Programmed
6. Service (downflow)
